ORVAL HYDRAULIC was established in 1996 in order to meet all the de­mands related to hydraulic directional control valves, which have an im­portant role in sectors such as machinery and machine systems and equ­ipment used and produced in industry, agricultural tools, maritime sec­tors, mobile cranes, garbage trucks.


Contact Information


0 (332) 345 29 29



Büsan Özel Org. San. F. Çakmak Mh. Kosgeb Cd. 10641 Sk. No: 37 KONYA / TÜRKİYE



Nominal Flow Rating Displacement 45 l/min 12 U.S.G.P.M
Maximum Working Pressure (Series Circuit) 315 Bar 4600 PSI
Max Back Pressure 25 Bar 360 PSI
Oil Temperature with NBR Seals -20 to 80 C° -4 to 176 F°
Oil Temperature with FPM (Viton) Seals -20 to 100 C˚ -4 to 212 F ˚
Tie Rod Tightening Torgue 30 Nm 22 lbft
ORV-STY Outlet With 2 Port
ORV-STY Outlet With 4 Port
ORV-STY Outlet With 6 Port
