| MODEL | TE CT-25 | CE CT-25 | TE TT-25 |
| Nominal Flow Displacement - Totaly | Oil Temperature with FPM (Viton) Seals |
| Nominal Flow Displacement - Pull Direction | 14,5 cc/cycle - 0,004 U.S.G/cycle |
| Nominal Flow Displacement - Push Direction | 10,5 cc/cycle - 0,003 U.S.G/cycle |
| Maximum Operating Pressure | 300 Bar - 4400 PSI |
| Oil Temperature with NBR Seals | -20 to 80 C° (-4 to 176 F°) |
| Oil Temperature with FPM (Viton) Seals | -20 to 100 C° (-4 to 212 F°) |
| Oil Temperature with FPM (Viton) Seals | 19/16 - ISO 4406 |
